SPECIFICATIONS
Frequency Response
10 Hz to 20 KHz
THD & Noise
.075%
(1Khz @ +4 dBm) Mic Pre
.06%
(1Khz @ +4 dBm) Limiter
Signal to Noise ratio
107 dB
Limiter
Headroom
26 dB (ref +4 dBv)
Limiter
Maximum Output
+30 dBv (75 volts p to p) Limiter
Maximum Input (with Input at max)
70 mV mic,
800mV direct
Maximum Gain (factory set for 45 dB)
38 dB to 53 dB (internal trimmer) Mic
25 dB Direct Instrument 1/4” input
(knob set to 45 dB)(off to +40 dB range)
15 dB
Limiter
Maximum Limiting
20 dB
11 dB w +4 sine
Attack Time (fixed)
20 mS
Release Time (fixed)
500 mS
Input Impedance
2400 Ohm, transformer coupled
(optimised for mics with 100 to 600 ohm output impedances)
150,000 Ohm @ 1/4” direct input
Output Impedance
11 Ohms (balanced)
6 Ohms (unbalanced)
XLR Pin-Out (balanced)
PIN 1 = Ground or Shield (not appropri-
ate for driving unbalanced inputs)
PIN 2 = HOT (+)
PIN 3 = LOW (-)
1/4” Phone Jack Pin-Out (unbalanced)
Sleeve = Ground or Shield
Tip = Signal
(We suggest mono plugs, but if a stereo plug must be used the Ring needs to be con-
nected to the Sleeve)
Power Consumption
20 watts
Size
19” X 3.5” X 10”
(1U) Shipping Weight
20 lbs
