Cylinder number and RPM calibrate number 4 Cyl engine
Number
of
Cylinders
4-Stroke
pulses/Crank-
Rotation Calibrate
Number Comment
1 1/2 1 Use also when using inductive
clamp on spark wire or power
wire of COP system of 1 cylinder
only for all cylinder numbers
2 1 2 Use also when using inductive
clamp on spark wire or power
wire of Waste spark coil of 1
cylinder only.
Waste spark system:
1 coil for every 2 cylinders.
3 1-1/2 3
4 2 4
5 2-1/2 5
6 3 6
8 4 7
10 10 8
12 12 9
Cylinder number and RPM calibrate number 2 Cycle and Rotary Engine
Number
of
Cylinders 2-Stroke
pulses/Crank-
Rotation Calibrate
Number Comment
1 1 2 Use also when using inductive
clamp on spark wire or power
wire of COP system of 1 cylinder
only for all cylinder numbers
Also use for rotary engine.
2 2 4 Use also when using inductive
clamp on spark wire or power
wire of Waste spark coil of 1
cylinder only.
Waste spark system:
1 coil for every 2 cylinders.
3 3 6
4 4 8
5 5 8
6 6 9
Once the selection is made press Enter. You will be brought back to the main
screen.
