4
2. CLEANING
a
Using the wipes provided test a small area to make sure
it does not affect the mounting surfaces. Clean the installation surfaces free of
dust/grease to assure the two-sided tape adheres well.
3. MOUNTING CLIPS Mounting clips can be secured using the two-sided
tape or screws. DO NOT USE SCREWS FOR FASTENING TO
ELECTRONIC DEVICES AND SENSITIVE SURFACES.
CAUTION: Tapes may cause discoloration to some surfaces over time.
Remove one side of the tape liner and apply to the bottom of the clips. Apply
pressure for 5 seconds to assure adhesion. Place clips on the lightbars.
4. LIGHTBAR PLACEMENT Remove the second side of tape liner. Keep the
tape surface clean. Place the bars in the proper location by pressing on the clips
for 5 seconds. CAUTION: Never press on the clear lens of bars. Lightbars will
get damaged! Note the direction of the wires being routed to the hub.
5. HUB Mount the hub using screws or tapes. Plug the lightbar connectors into
hub outlets. The plugs are polarized and can only be plugged in one direction.
6. CONTROLLER Use tape to mount the controller in an accessible location.
Some painted surfaces may get damaged upon future removal of the
tape/controller.
7. POWER UP Plug the power supply into an AC outlet. The plug is polarized
(one blade is wider than the other) as a feature to reduce the risk of electric
shock. This plug will fit in a polarized outlet only one way. If the plug does not
fit fully in the outlet, reverse the plug. If it still does not fit, contact the factory
or a qualified electrician. Never use with an extension cord unless the plug can
be fully inserted. Do not alter the plug.
8. DC JACK Connect the DC power jack into the controller DC cord.
Operations
Turn the unit on and adjust the light angle by twisting the lightbars within the
brackets. Try several angles to achieve the desired results.
