I-155 TS2
FRONT END (s.n. 20412 and up)
Key Number Part Number Description
1 A123329 Front End Assembly
2 A123320-08 Bronze Bushing: 3"ID X 3 1/2 OD X 3"L
3 A123456 Trunion Mount Block
4 AFB-00039 Bolts, 3/4" X 5 1/2"
5 AFW-00002 Lockwasher, 3/4"
6 A123321-09 Pin: Main Frame Attachment
7 A125179 Bushing for Trunion Mount Block
8 A125005 Accumulator
9 A125009 Mounting Brackets
10 A125109A Hose Support
11 A123358 Flanged Bolt Bushing
12 AFB-00079 Bolt: 5/8" X 1 1/2" Gr 8
13 A123320-20 Travel Lock
14 AFB-00021 Bolt: 1" X 5 1/2" NC Gr. 8 (9 Reqd).
15 AFN-00037 Nut: 1" NC Locknut (9 Reqd).
