Ashland I-130 - Manual (Page 6)

KEY NO. PART NO. DESCRIPTION
1
A13001 Gooseneck frame
A13011 Gooseneck frame, s/n 17806 & up,
cyl ears 1-1/4" hole spaced 2"
2 AFB-00054 Bolt, 1/2" NC x 3-1/2" w/ nut (nut #7500)
3 14505 Grease zerk, straight
4 A10152A Pin, Frame attachment, 2” OD x 8-1/16” Long
5 Hair pin
6 A10153 Pin, Transport lock
7 AFB-00081 Bolt, 7/8" NF x 5"
8 7610 Nut, 7/8" NF
9 8125 Lockwasher, 7/8"
10 A14002 Cast socket half, rear
11 A14003 Cast socket half, front w/ zerk hole
12 A2206 Grease zerk, long shank
13 ** A14039 Bushing, 2.375 OD x 2.00 ID x 2” Long, Grease Passage
For serial number 20319 and above
6
