Ashland I-130 - Manual (Page 18)

PARTS LIST- HYDRAULIC CIRCUIT
KEY NO. NO. REQ’D PART NO. DESCRIPTION
1
5 A101H72 Swivel adapter, str. 3/4 male x female
2 2 A101H32 Hose, 3/4 x 21 long
3 3 A101H31A Hose, 3/4 x 24-1/2 long
4 1 Hose, 3/4 x 28 long
5 5 Elbow, 90° x 3/4 NPT, Steel
6 2 Pipe, 3/4 x 48-3/4 long
7 2 Pipe, 1/2 x 38-1/4 long
8 2 Pipe, 1/2 x 35-3/4 long
9 7 Pipe bushing, 1/2 NPT x 3/4 NPT
10 9 Pipe tee, 3/4 NPT, Steel
11 4 Elbow, 90°, 1/2 NPT, Cast
11A 2 Elbow, 90°, 1/2 NPT, Steel
12 3 A45H06 Hose, 1/2 x 24 long
13 2 A45H07 Swivel adapter, 90°, 3/8 NPT x 1/2 NPT
14 2 A60H01A Hose, 1/2 x 18 long
15 2 Pipe, 3/4 x 78-1/2 long
16 3 A101H35 Swivel adapter, str. 3/4 female x female
17 2 A101H36 Hose, 3/4 x 33 long
18 1 Street elbow, 45° x 3/4 NPT
19 4 Street elbow, 90°, 3/4 NPT, Steel
20 1 A101H82 Hose, 1/2 x 56 long
21 1 A80H29 Hose, 1/2 x 46 long
22 1 Pipe, 3/4 x 28 long
23 1 Pipe, 1/2 x 98 long
24 1 Pipe, 3/4 x 45-3/4 long
25 2 Pipe, 3/4 x 7 long
26 6 A101H77 Swivel adapter, 90°, 3/4 NPT
27 1 A101H38A Hose, 3/4 x 71 long
28 1 A140H17A Hose, 3/4 x 77 long
29 1 A130H21 Hose, 3/4 x 56 long
30 1 Pipe, 1/2 x 42-3/4 long
31 1 Pipe, 3/4 x 46-3/4 long
32 3 A101H73 Street elbow, 90°, 1/2 NPT, Steel
33 1 A101H74 Swivel adapter, str. 1/2 female x female
34 1 Pipe, 1/2 x 11-3/4 long
35 1 A101H42 Hose, 3/4 x 42 long
36 5 A400H02 Swivel adapter, 90° x 1/2 NPT
37 1 A101H75 Check valve
38 1 A101H48 Counterbalance valve
39 1 Pipe nipple, 3/4 x 5-1/2 long
18
