SYNC
A bi-color LED indicator is provided to monitor the proper serialization of the electrical video
data stream through the MRX-91685C-SL. A SYNC indicator for videos one through eight is
located above the OLI 1 indicator. A SYNC indicator for videos nine through sixteen is located
above the OLI 2 indicator. Sync status associated with these LED’s is summarized below.
Sync LED Sync Status
Green Proper Data Stream Serialization Present
Red Data Stream Serialization Not Detected
OLI 1
A bi-color LED indicator monitors the power of the optical input signal that is being received at
the MRX-91685C-SL from video channels one through eight of the MTX-91685C-SL. AC power
and optical input status associated with this LED are summarized below. Please note that data
is sent to the MRX-91685C-SL with this optical input signal.
Optical Level Indicator AC Power Status Optical Status
Green On Proper Optical Input Power Present
Red On Optical Input Not Detected
Off Off Check Power Supply Input
OLI 2
A bi-color LED indicator monitors the power of the optical input signal that is being received at
the MRX-91685C-SL from video channels nine through sixteen of the MTX-91685C-SL. AC
power and optical input status associated with this LED are summarized below.
Optical Level Indicator AC Power Status Optical Status
Green On Proper Optical Input Power Present
Red On Optical Input Not Detected
Off Off Check Power Supply Input
