Ag-Bag G6060 User Manual
Page 7
Description
Quantity
Part No.
Item
Frame Weldment - (S/N 42.05167 & Before)
1
42.0900586
1
Frame Weldment - (S/N 42.05168 & After)
1
42.0901595
Stripper Plate - 45 in. Weld In G6070 (Non Gearbox End)
AR
42.0000093
1a
Stripper Plate - 35 in. Weld In G6060 (Gearbox End)
AR
42.0000094
1b
Stripper Plate - 33 in. Weld In G6060 (Non Gearbox End)
AR
42.0000095
1c
Bearing, Drive, 3-7/16 in. Spherical 4 Bolt Footed - (S/N 42.05168 & After)
1
42.0900372
2
Bearing, Drive, 2-15/16 in. 4 Bolt Footed
1
42.0900371
3
Rotor + Four Teeth & Caps - 2-15/16 in. Shaft (Weld Req`d) (S/N 42.05167
& Before)
1
42.0901137
4
Rotor + Four Teeth 3-7/16 in. Shaft - (Weld Req`d) (S/N 42.05168 & After)
1
42.0901825
Stub Shaft Drive, Weld In - (S/N 42.05168 & After)
1
42.0900380
4a
Stub Shaft Drive, Weld In - (S/N 42.05167 & Before)
1
42.6002005
Stub Shaft Idle, 2-15/16 in. Weld In
1
42.6002008
4b
Tooth Assembly w/Cap
48
42.1020018
4c
Cap, Rotor Tooth, Weld On
48
42.1020001
4d
Bearing, 4 Bolt Flange
2
42.1510044
5
Gearbox, Dual Output - Aluminum
1
42.0901808
6
Bearing, Split Babbit
2
42.1510047
7
Drum, Cable, w/Brake Flange, 7 Ft Rotor - 6070 Only
2
42.0900246
8
Weldment, Rotor Access, Drive - (S/N 42.05168 & After)
1
42.0900445
9
Weldment, Rotor Access, Drive - (S/N 42.05167 & Before)
1
42.0900349
Weldment, Rotor Access, Idle
1
42.0900447
10
Bolt, Hex, 3/4-10 x 3-1/2 in. Gr 5
8
904215
11
Nut, Hex Lock, 3/4-10 Nylock
8
906349
12
Washer, Lock, 5/8 in. Yellow Zinc
8
900508
13
Bolt, Hex, 5/8-11 x 2 in. Gr 5
8
904253
14
Bolt, Hex, 1/2-13 x 1-3/4 in. Gr 5
8
903518
15
Nut, Hex Lock, 1/2-13 Nylock
16
906401
16
Bolt, Hex, 1/2-13 x 1-1/2 in. Gr 5
8
903306
17
Bolt, Hex, 5/8-11 x 2-1/2 in. Gr 5
4
903832
18
Nut, Hex Lock, 5/8-11 Nylock
4
906402
19
Coupling, Cable Drum
1
42.6003021
20
Cable Drum, Non Brake Side, 6 Ft Rotor
1
42.6003024
21
Cable Drum, Brake Side, 6 Ft Rotor
1
42.6003025
22
Key, Square, 3/8 in. x 3 in. Undersize
2
01.73266
23
Hitch, Field, 8-9 Ft w/Decals
1
42.0901793
24
Jack, Manual, 15 in. Square Mount
1
42.1501398
25
Pin, Hitch
1
42.1550172
26
Pin, Hair
1
05.73120
27
Mount, (Weld On), Jack, Female Square Tubing
AR
42.1501400
28
G6060
- 7 -
42.0901804A Issue Date: 09/11
Section 1
1.01 Frame with Rotor & Cable Drums G6060
