Ag-Bag G6060 - Manual (Page 27)

Description Quantity Part No. Item
Cotter Pin, Stainless Steel Hair Pin 1 907472 1
Nut, Hex Lock, 5/16-18 Nylock 5 906483 2
Nut, Hex Lock, 1/2-13 Nylock 4 906401 3
Washer, Flat, 5/16 in. 5 904324 4
Bolt, Carriage, 5/16-18 x 1 in. Gr 5 5 903690 5
Bolt, Carriage, 1/2-13 x 1-1/2 in. Gr 5 Short Neck 4 908333 6
Pin, Spring, 5/16 in. x 3 in. 2 901850 8
Fitting, Grease, 1/8-PTF 2 900537 9
Machine Bushing, 1-1/4 in. 2 900512 10
Weldment, Conveyor End Frame 1 42.0901034 11
Bearing, R-Lube, 1-1/4 in. 2 Bolt 2 42.0901019 12
Pin, Conveyor Door Latch 1 42.0901009 13
Clean Out Door w/Decals 1 42.0901767 14
Deflector Weldment, Adjustment End 1 42.0901003 15
Shaft, 1-1/4 in. x 34-3/4 in. 1 42.0901002 16
Conveyor Roller, 1.250 in. Bore 4 42.0900987 17
Adapter (For Bearing With 1/4-28 Thread) AR 42.1541519 18
G6060 - 27 - 42.0901804A Issue Date: 09/11
Section 3
3.05 Lower Assembly, Split Conveyor - G6060, G6070 &
G6070P (S/N 42.04940 & After)
