Ag-Bag G6060 - Manual (Page 57)

Description Quantity Part No. Item
Yoke, #6/S7, 1-3/8 in. Z6 Ball 1 42.0901553 1
Cross Kit, #6, 30.2 x 91.4 2 42.1500875 2
Yoke 1 42.1501636 5
Flexible Roll Pin, #6/7 Outer, 10 x 75mm 1 42.1501853 8
Tube 1 42.0901555 12
Tube, CARDAN #6 Inner 1 42.0901556 13
Flexible Roll Pin, #6/7 Inner, 10 x 65mm 1 42.1520749 16
Yoke, #6 Inner Tube 1 42.1501858 17
Yoke, Ball Shear #6, 1-3/4 in. 27QD 1 42.0900043 21
Shield Support, #6-7 Outer 6G502 1 42.1501047 26
Safety Tube (Not Serviced Separately) 1 NSS 29
Safety Tube (Not Serviced Separately) 1 NSS 30
Shield Support, #6-7 Inner 6G602 1 42.1501048 32
I.Cone, Shield Cone, #5-6-7 Inner (Not Serviced Separately) 1 NSS 33
I.Cone, Shield Cone, #5-6-7 Inner (Not Serviced Separately) 1 NSS 35
Danger Label, Outer Drive Tube 1 331639B2 48
Danger/Shield Label 1 329594B2 49
Instruction Booklet (Not Serviced) 1 NSS 50
Kit, Ball Collar, 1-3/8 in. #6 1 42.0901557 51
Kit, RT Ball Collar S5/S9, 1-3/4 in. 1 42.0000692 65
Grease Fitting, M6 x 1 Straight (Not Serviced Separately) 1 NSS 72
Screws, Bolt-Nut M10 x 50mm CL8.8 1 42.0900156 76
Half Shaft, Uncleared (Not Serviced Separately) 1 NSS 91
Half Shaft, Uncleared (Not Serviced Separately) 1 NSS 92
Half Shaft, Cleared (Not Serviced Separately) 1 NSS 93
Half Shaft, Cleared (Not Serviced Separately) 1 NSS 94
Half Shield Kit (Not Serviced Separately) 1 NSS 95
Half Shield Kit (Not Serviced Separately) 1 NSS 96
Complete Shield Kit 1 42.0901558 97
PTO Shaft, Complete 1 42.0000041 98
G6060 - 57 - 42.0901804A Issue Date: 09/11
Section 8
8.02 PTO Shaft - PB6000 & (G6060 up to 2009 Production)
