Ag-Bag G6060 User Manual
Page 23
Description
Quantity
Part No.
Item
Bolt, Hex Washer Hd, 3/8-16 x 3/4 in. Gr 5
2
09.71251
1
Pin, Roll, 3/8 in. x 2 in.
4
09.72010
2
Hinge, Beater Shield
2
16.20144.5
3
Chain, #40-2, 16 Pitches w/ Connector
1
22.00188
4
Sprocket, 40B16, 1 in. Bore
1
303629B1
5
Sprocket, 50B20, 1.25 in. Bore
2
42.0900004
6
Chain, Roller, #50, 114 Pitches
1
42.0900005
7
Hose, Grease, 3/16 in. x 47 in.
1
42.0900006
8
Hose, Grease, 3/16 in. x 32 in.
1
42.0900007
9
Apron, Short, 16 Slat
1
42.0900019
10
Conveyor Lower Assembly - Not Serviced Separately Refer to Lower Assembly
Split Conveyor Page for Parts Breakdown
1
NSS
11
Adjuster, Chain
2
42.0901011
12
Sprocket, CA550, 6 Tooth
4
42.0901014
13
Bearing, R-Liube, 1-1/4 in. 2 Bolt
4
42.0901019
14
Weldment, Conveyor
1
42.0901020
15
Shaft, RH Drive
1
42.0901022
16
Shaft, 1.25 in., LH
1
42.0901023
17
Bracket, Bearing Bolts
1
42.0901035
18
Bracket, w/Bolts, Adjuster
2
42.0901037
19
Mount, Bracket, Drive Motor
1
42.0901393
20
Cover, Drive Chain
1
42.0901394
21
Shield, Motor
1
42.0901397
22
Plate, Bearing Mount
2
42.0901402
23
Hold Down, Conveyor Chain, Short
1
42.0901438
24
Hold Down, Conveyor Chain, Long
1
42.0901439
25
Deflector, 2 Stage Conveyor w/Decal
1
42.0901796
26
Sprocket, DBL
1
42.0901688
27
Hose, Grease, 3/16 in. x 40 in.
1
42.1501519
28
Adaptor, #2 MP x #2 FPS
3
42.1501611
29
Whip, Grease, 3/16 in. x 21 in.
1
42.1502166
30
Strip, Conveyor skirting, Center
1
42.6008020
31
Strip, Conveyor Skirting, Side
2
42.6008021
32
Skirt, Conveyor, 20 in. x 60 in.
1
42.6008052
33
Chain, Conveyor, Long w/Weld On Flight
1
42.6008077
34
Sprocket, Idler, 50B17, .643 in. Bore
1
900188
35
Nut, Hex, 1/2-13
12
900369
36
Bolt, Carriage, 3/8-16 x 1 in.
2
900480
37
Washer, Flat, 1/4 in. SAE Yellow Zinc
13
900493
38
Washer, Flat, 7/16 in.
3
900496
39
Washer, Flat, 5/8 in.
1
900498
40
Washer, Lock, 1/2 in.
4
900506
41
G6060
- 23 -
42.0901804A Issue Date: 09/11
Section 3
3.04 Split Conveyor (S/N 42.04940 & After)
