Brewer Element Treatment 2030/2040 User Manual

Page 8

Document 101290 RevA

MODELS 2030 and 2040 STEP 6

Screw A

Screw B

J-Bolt R

Foot End

Dowel Rod

Rounded

Corner

Back Section

Backrest
Bracket

STEP A: Rotate Back Section until Backrest Bracket is engaged or top is horizontal on frame.

STEP B: Set upholstery bottom on frame, with Rounded Corners placed at the Foot End of the table.

STEP C: Install Screw A (1/4”-20 x 4”) through frame and into upholstery.

STEP D: Install 2 Screws B (1/4”-20 x 2”) through frame and into upholstery.

STEP E: Tighten Screws.

STEP F: Slide the Dowel Rod through the paper roll and hang the Dowel Rod on the J-Bolts. Ensure a
secure fit before using the paper roll dispenser.
