MODELS 2030 and 2040 STEP 3
Backrest Catch
Screw G
Nut H
Screw B
Snap Rivet
Snap Rivet
STEP A: Install Backrest Catch as shown in the drawing above.
CAUTION
! The Backrest Catch needs to be positioned on top of the Tab shown in STEP 2.
STEP B: STEP B: Install Screw B (1/4”-20 x 2”) through frame rail and into Backrest Catch and tighten Nut H
(1/4”-20). Insert Screw G (1/4”-20 x 1/2”) through Backrest Catch and Tab. Tighten Nut H onto Screw G.
STEP C: Install two Snap Rivets into the frame rail as shown.
