MODELS 2030 and 2040 STEP 4
STEP A: Align holes in Hinge with holes in frame. Hinge must be oriented as shown with Hinge mounting
flange facing the Head End of the table.
STEP B: Install 4 Screws G (1/4”-20 x 1/2”) into the Hinge and through the frame. Fasten with 4 Nuts H
(1/4”-20) and tighten.
Screw G
Nut H
Head End
Detail of Hinge
Assembly
