M3N78-EM specifications summary
High Definition Audio Realtek ® ALC 1200 High Definition Audio 8-channel
CODEC
Supports S/PDIF out port at back I/O, Jack-detection and
Multi-streaming
USB 12 USB 2.0 / 1.1 ports (6 ports at mid-board, 6 ports at
rear panel)
LAN NVIDIA ® built-in Gigabit MAC with external Realtek
PHY
ASUS Unique Features ASUS Express Gate:
- Web browser, file downloading and uploading*
- Further free features upgradable
* File downloading and uploading is supported through USB
devices only..
ASUS Quiet Thernal Solution:
- ASUS Q-Fan
ASUS EZ DIY:
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 2
Other Feature:
- ASUS MyLogo 2™
ASUS Overclocking
Features
Precision Tweaker:
- vCore: 4-step CPU voltage control
- vDIMM: Adjustable DRAM voltage at 0.00625V
increment
- vChipset: 4-step chipset voltage control
Stepless Frequency Selection (SFS):
- SB tuning up to 300MHz at 1MHz increment
Overclocking Protection:
- ASUS CPU Parameter Recall (C.P.R.)
BIOS features 8 Mb Flash ROM, AMI BIOS, PnP, DMI2.0, WfM2.0,
SM BIOS 2.5, ACPI 2.0a
Rear panel I/O 1 x LAN (RJ-45) port
1 x HDMI port
1 x DVI port
1 x VGA Out port
1 x External SATA port
1 x Optical S/PDIF Out port
1 x IEEE 1394a port
6 x USB 2.0 / 1.1 ports
1 x PS/2 keyboard/mouse combo port
8-channel audio ports
(continued on the next page)
