Installation
15 510963
Reversing Door Procedure
The door on this dryer is completely reversible. To
reverse door proceed as follows:
D675I
1
Remove four hinge
attaching screws.
D675I
2
Remove all nine
screws.
D272P
DRY1916N
B
A
3
Pull bottom of door
liner out, then pull
down, removing
door liner from
door panel.
DRY1916N
4
Rotate door panel
180 degrees as
shown.
D273P
DRY1917N
5
Remove door strike
from door liner and
reinstall on opposite
side.
DRY1917N
DRY1918N
B
A
6
Insert liner under
flange on bottom of
door, then push top
of door liner into
place.
DRY1918N
DRY1919N
7
Reinstall nine
screws removed in
Step 2.
DRY1919N
D620I
8
Using the screwdriver,
remove two door
plugs, and reinstall on
opposite side of door
opening.
D620I
D623I
9
Reinstall four hinge
attaching screws.
removed in Step 1.
