monogram.com
65
Telescopic downdraft vents
36" telescopic
downdraft vent
ZVB36STSS
Overall dimensions
(WxHxD in inches):
36 x 8-1/2 x 2-1/8
Amps @ 120VAC
4
Approx. shipping wt. (lbs.) 74
• 3-1/4" x 10" rectangular duct
• Stainless steel vent body
• Indoor remote blower kit
30" telescopic
downdraft vent
ZVB30STSS
Overall dimensions
(WxHxD in inches):
30 x 8-1/2 x 2-1/8
Amps @ 120VAC
4
Approx. shipping wt. (lbs.) 69
• 3-1/4" x 10" rectangular duct
• Stainless steel vent body
• Indoor remote blower kit
General features
Powerful ventilation. A 3-1/4" x 10" rectangular duct and a
durable, stainless steel vent capture smoke and odors at the
cooking surface. A variable-speed fan blower exhausts the air
at a rate of 390 CFM at high speed.
Removable filters. Filters can be easily removed for safe
cleaning in your dishwasher.
Remote blower placement installation kit. To reduce noise
in the kitchen, an indoor installation kit is offered for remote
blower placement.
For additional details on product installation, warranty
coverage, care and maintenance, visit monogram.com.
Important installation note: The installation of these downdraft
vents in combination with any Monogram
® cooktop requires an
extra-deep countertop. The flat surface of the countertop must
be deep enough, front to back, to accommodate the combined
depth of the vent and cooktop. Additional clearances required
by UL from the cutout to the front edge of the countertop
also vary by model and must be considered. Be sure to
review the downdraft vent installation instructions carefully.
These instructions provide exact cutout and countertop area
requirements for the installation of the vent with each specific
Monogram cooktop.
ZVB36STSS ZVB30STSS
