26
Number of ports
The following table lists the ports.
Category Port number Speed Description
Internal interface
CPU Blade 1-16 10Gbps The ports dedicated to the CPU Blade. Each port
connects with each CPU Blade installed the
Blade Slot in the Blade Enclosure. The
connection is difference between the Blade
Enclosures. Refer to page 28
“Connection with
CPU Blade ”.
Management network 17 10/100Mbps The port dedicated to management network. Port
17 is isolated from the other ports by using
VLAN. Use port 17 for managing the Switch
Module. To connect the management interface,
connect the port in the Blade Enclosure. For
more information, see the Blade Enclosure
User
’s Guide.
External interface
Uplink
(XFP module slot)
18-21 10Gbps Uplink ports using optional N8406-027 XFP
modules
Serial port - 9600bps DB-9 management serial port
NOTE: By default, VLAN 1 is the default VLAN, and all ports except Port
17 are assigned to it.
