Technical Information
7
1. TECHNICAL INFORMATION
1.1. Necessary tools for installation
 Shipping restraints ........................... flat spanner 15/16 inch (24mm)
 Shipping restraints ........................... offset ring wrench 15/16 inch (24mm )
 Covers fixing .................................... flat spanner 3/8 inch (10mm ); 1/2 inch (13mm )
 Covers fixing .................................... screwdriver Torx T20.
 Water inlet pipes .............................. adjustable wrench or slip-joint pliers 2.5-2.8 inch. (65-70 mm)
 Water and steam inlet filters............. adjustable wrench or slip-joint pliers 2.5-2.8 inch. (65-70 mm)
 Cable ties......................................... socket key 7mm
 Electrical requirements .................... screwdriver Phillips 2. (#2)
 External dosing connection .............. screwdriver 3mm
1.2. Machine accessories
Keep all the machine’s documentation in a safe place
ACCESSORY QUANTITY NOTES
Set of water inlet hose filter ................ 2 (1)
Steam outlet elbow ............................. 1
Steam outlet elbow clamp .................. 1
Steam inlet valve and filter (2) ............ 1
Steam inlet coupling (3) ...................... 1
Fuses ................................................. (4)
Installation Instructions ....................... 1
Operation Instructions ........................ 1
Parts handbook (5) ............................. 1
Other documentation ......................... (5)
(1) machines with third water inlet: 3 units
(2) steam connection accessories in TILT
machines: refer to section 3.4.
(3) Steam connection accessories in TILT
machines: refer to section 3.4.
(4) depending on machine model and
voltage
(5) depending on target country
