5
5 Input for Microphone and line provided with balanced 1/4" jack and XLR. Channel 5 features stereo Line input
1 additional input for Line level signal provided with balanced TRS 1/4" jacks
The Microphone preamplifiers are Ultra Low Noise and are provided with +48 Volt Phantom Power
1 pre-fader and 1 post-fader Auxiliary bus
Main Output is balanced to provided optimum sound quality. Control Room and headphone output are unbalanced
type
Precise 3 bands graphic equaliser (Bass, Middle and treble) on each input channel
Single Led indicating signal Peaks on each input channel and Low-cut filter on all mono MIC channels
2-track input featuring RCA sockets assignable alternatively to each output group
12 Segments Led Meter for optimum reading of the output signal
Balanced Outputs both XLR and TRS 1/4" jack
2. FEATURES
Your S-8 is provided with 4 mono Line/Mic input, 1 stereo Line/Mic input and an additional stereo Line input to be used
with keyboards, Midi Instruments, etc. We have even included a 2-track input/output for recording and playback. Ultra
low noise microphone preamplifiers, 3 bands eq on all input channels, pre and post Auxiliary bus and phantom power
complete the picture.
