user’s guide 19
Video Modes
Your LCD monitor supports the following industry-
standard combinations of screen resolution and
refresh rates. Other combinations are possible, but
may require adjustments to the image.
For optimum performance, set your PC to a screen
resolution of
1024 x 768 at a 60 Hz refresh rate.
Supported Resolution
(dots x lines) Vertical
Frequency
(Refresh Rate)
VGA 640 x 480
640 x 480
640 x 480
640 x 480
640 x 350 60 Hz
70 Hz
72 Hz
75 Hz
70 Hz
SVGA 800 x 600
800 x 600
800 x 600
800 x 600
800 x 600 56 Hz
60 Hz
70 Hz
72 Hz
75 Hz
XGA 1024 x 768
1024 x 768
1024 x 768
1024 x 768 60 Hz
70 Hz
72 Hz
75 Hz
US TEXT 720 x 400 70 Hz
Power
MAC 640 x 480
832 x 624 67 Hz
75 Hz
NOTE: The display is capable of going beyond these
recommended modes.
Unknown Video Modes
Like all other monitors, the your LCD monitor is
designed to work with standard video modes.
However, not all video/graphic cards use only
standard display modes.
Your LCD monitor uses state-of-the-art technology,
which is designed to automatically synchronize to
any display video mode listed in the above table. We
recommend that you choose one of the supported
video modes listed above. If you choose an unknown
video mode, you will need to manually adjust the
clock, phase, and image position; the resulting
display may still be bad.
If you must use an unknown mode that is not in the
listed display video modes, you should run Auto
Setup first. If Auto Setup doesn’t provide adequate
image adjustment, then you must manually adjust
the clock, phase, horizontal position, and vertical
position. If this does not work, please chose a
recommended video mode.
Recycling your Product
HP has a strong commitment toward the
environment. Your monitor has been designed to
respect the environment as much as possible.
HP can also take back your old monitor for recycling
when it reaches the end of its useful life.
HP has a product take-back program in several
countries. The collected equipment is sent to one of
HP’s recycling facilities in Europe or the USA. As
many parts as possible are reused. The remainder is
recycled. Special care is taken for batteries and other
potentially toxic substances, which are reduced to
non-harmful components through a special chemical
process. If you require more details about HP’s
product take-back program, contact your dealer or
your nearest HP Sales Office.
This product contains the following materials may
require special handling at the end-of-life:
•
Mercury in the liquid display.
