NOTE:

To view information on the screen in portrait mode, you can install the HP Display

Assistant software included on the software and documentation media disc. The position of the
OSD menu can also be rotated to portrait mode. To rotate the OSD menu, access the OSD
menu by pressing the

button on the front panel, select OSD Control from the menu, then

select Rotate OSD.

Removing the Monitor Pedestal Base

You can remove the monitor panel from the pedestal base to install the panel on a wall, a swing arm,
or other mounting fixture.

CAUTION:

Before beginning to disassemble the monitor, be sure the monitor is turned off and the

power and signal cables are disconnected. Also disconnect all USB cables connected to the monitor.

Disconnect and remove all cords and cables from the monitor.

Lay the monitor face down on a flat surface covered by a clean, dry cloth.

Pivot the base 45 degrees clockwise and remove the screw from the back of the monitor, then
pivot the base 45 degrees counter-clockwise and remove the other screw from the back of the
monitor.

Rotate the base of the monitor up (1) then pull it back (2) to unhinge the tabs on the monitor
stand from the slots in the monitor.
