EN
Placing
The appropriate site for the installation of
the unit is a dry and well-ventilated position.
It should not be affected by direct sunlight,
or be placed near a source of heat such as
a cooker, radiator etc. If it is inevitable that
the unit be installed next to a source of heat,
fit a suitable insulation plate or respect the
following distances from the source of heat:
For electric cooker
3 cm.
For oil-or coal-fired ranges
30 cm.
If the unit is to be installed next to another
refrigerator or freezer, a lateral distance of 2
cm. between the appliances should be left,
which is necessary in order to avoid the
formation of water vapour.
Clean the inside of the appliance thoroughly,
before using the first time (see cleaning).
Installation and changing the
opening direction of the doors
See enclosed assembly instructions.
Electrical connection
Connect the appliance to an alternating
current of 220-240 V (SN/N), 220-230 V
(ST) 50 Hz, and only to a plug socket which
has been installed in accordance with the
corresponding regulations.
The plug must be protected by a
circuitbreaker of 10A or more.
Ventilation
The warm air must be able to escape freely
at the back of the unit. If this is not the case,
the condenser has to work harder as a
result, and this increases electricity
consumption.
Therefore, under no circumstances cover
the ventilation grills or aeration vents.
Before reading, please open out the
illustrated pages at the back of this booklet.
The instructions for use apply to various
models, and variations in the illustrations
are possible.
Picture of the appliance
Fig a
1-9 Controls
10
Shelves
11
Bottle rack
12
Yoghurt drawer
13
Outlet for defrost water
14
Tray
15
Vegetable drawer
16
Egg rack
17
Cheese and butter compartment
18
Bottle shelf
19
Ice tray
20
Drawers for frozen products
21
Freezing calendar
22
Skirting
23
Outlet for defrost water
24
Fan
A
Refrigerator
B
Freezer
Control panel
Figure s
1 Refrigerator compartment on/off
button
2 Refrigerator compartment
temperature selector
3 Refrigerator compartment
temperature selection indicator
4 Interior light switch
5 Freezer compartment on/off button
6 Freezer compartment temperature
selector
7 Freezer compartment temperature
selection indicator
8 Fast freeze control button
9 Freezer compartment temperature
warning light (red)
Installing the unit
Getting to know the unit
13
