20
HP w22
Display Type 22 inches, TFT LCD 55.868 cm
Viewable Image Size 22-inch diagonal 55.868 cm
Tilt –5° to 20°
Face Treatment Antiglare polarizer with hard coating
(select models only)
Maximum Weight (unpacked) 13.89 lb. 6.3 kg
Dimensions (including pedestal)
Height
Depth
Width
17.18 inches
9.84 inches
20.74 inches
436.37 mm
249.94 mm
526.8 mm
Optimum Display Resolution 1680 x 1050 (60 Hz)
Text Mode 720 x 400
Dot Pitch 0.282 (H) x 0.282(V) mm
Horizontal Frequency 24 to 80 kHz
Vertical Refresh Rate 48 to 75 Hz
Audio Power Output 2W / channel @ PC 1 Vrms
Speaker (R/L) 2W / 16 ohm speaker
Power Consumption <55 watts typical
Input Terminal 1. VGA connector
2. DVI-D connector
Environmental Requirements
Temperature: Operating
Non-operating
41 to 104°F
–4 to 140°F
5 to 40°C
–20 to +60°C
Relative Humidity 20 to 85% (non-condensing)
Power Source 100–240 V , 50–60 Hz
Altitude: Operating
Non-operating
0 to 6,561.68 feet
0 to 40,000 feet 0 to 2,000 m
0 to12,192 m
