HP w22 20 inch LCD Monitor - Manual (Page 19)

19
Back to Contents Page
Specifications
HP w20 • HP w22 • Preset Display Modes • Power Cord Set Requirements • Pin Assignments •
Plug and Play DDC2B Feature
All specifications represent the typical specifications provided by HP’s component manufacturers; actual
performance may vary either higher or lower.
HP w20
Display Type 20.1 inches, TFT LCD 51.11 cm
Viewable Image Size 20.1-inch diagonal 51.11 cm
Tilt –5° to 20°
Face Treatment Antiglare polarizer with hard coating
(select models only)
Maximum Weight (unpacked) 13 lb. 5.9 kg
Dimensions (including pedestal)
Height
Depth
Width
15.98 inches
9.84 inches
19.14 inches
405.89 mm
249.93 mm
486.16 mm
Optimum Display Resolution 1680 x 1050 (60 Hz)
Text Mode 720 x 400
Dot Pitch 0.258 (H) x 0.258 (V) mm
Horizontal Frequency 24 to 80 kHz
Vertical Refresh Rate 48 to 75 Hz
Audio Power Output 2W / channel @ PC 1 Vrms
Speaker (R/L) 2W / 16 ohm speaker
Power Consumption <55 watts typical
Input Terminal 1. VGA connector
2. DVI-D connector
Environmental Requirements
Temperature: Operating
Non-operating
41 to 104°F
–4 to 140°F
5 to 40°C
–20 to +60°C
Relative Humidity 20 to 85% (non-condensing)
Power Source 100–240 V , 50–60 Hz
Altitude: Operating
Non-operating
0 to 6,561.68 feet
0 to 40,000 feet 0 to 2,000 m
0 to12,192 m
