Installing the Stand
CAUTION: Do not touch the surface of the LCD panel. Pressure on the panel may cause non-
uniformity of color or disorientation of the liquid crystals. If this occurs the screen will not recover to its
normal condition.
The display uses the HP Quick Release 2 for easy moving of the monitor. To mount the panel onto
the stand:
1. Lay the monitor panel face down on a flat surface covered by a clean, dry cloth.
2. Slide the top of the mounting plate (1) on the stand under the upper lip of the recess in the back
of the panel.
3. Lower the bottom of the stand's mounting plate (2) into the recess until it snaps into place.
4. The HP Quick Release 2 latch (3) pops up when the stand is locked in place.
NOTE: If you are mounting the monitor to a mounting fixture instead of the stand refer to Mounting
the Monitor on page 20 .
6 Chapter 3 Setting Up the Monitor
