Attaching the Cables: HP w19 LCD Monitor
Cable Connections On Back of Monitor and Computer
Turn off your computer before performing the procedure below.
1 Connect the power adapter DC cable to the DC-In port on the back of the monitor.
2 Connect one end of the 15-pin D-Sub (VGA) cable to the back of the monitor and connect the other end to the
computer’s D-Sub port.
3 Plug the power cable of your monitor into a nearby outlet. Plug the other end of the power cord into the power
adapter.
4 (Optional – Requires a video card with DVI port) — Connect one end of the 24-pin DVI cable to the back of the
monitor and connect the other end to the computer’s DVI port.
5 Turn on your monitor and computer.
If your monitor displays an image, installation is complete. If it does not display an image, see
and
.
