Power Cord Set Requirements
The monitor power supply is provided with automatic line switching (ALS). This feature allows the monitor to operate
on input voltages between 100–120V or 200–240V .
The power cord set (flexible cord or wall plug) received with the monitor meets the requirements for use in the
country/region where you purchased the equipment.
If you need to obtain a power cord for a different country/region, you should purchase a power cord that is approved
for use in that country/region.
The power cord must be rated for the product and for the voltage and current marked on the product’s electrical
ratings label. The voltage and current rating of the cord should be greater than the voltage and current rating marked
on the product. In addition, the cross-sectional area of the wire must be a minimum of 0.75 mm² or 18AWG, and the
length of the cord must be between 4.94 ft. (1.5 m) and 12 ft. (3.6 m). If you have questions about the type of power
cord to use, contact your HP-authorized service provider.
A power cord should be routed so that it is not likely to be walked on or pinched by items placed upon it or against it.
Particular attention should be paid to the plug, electrical outlet, and the point where the cord exits from the product.
Pin Assignments
Pin Number 15-Pin Side of the Signal Cable
1 Video-Red
2 Video-Green
3 Video-Blue
4 Ground
5 Ground
6 GND-R
7 GND-G
8 GND-B
9 +5V
10 Detect Cable
11 Ground
12 DDC-Serial data
13 H-sync
14 V-sync
15 DDC-Serial clock
