Managing the HAFM application 82
The Add Trap Recipient dialog box is displayed ( Figure 39 ).
Figure 39 Add Trap Recipient dialog box
5. If you want this trap recipient to be active, select the Activate check box.
6. Enter the IP address or DNS host name of the trap recipient in the IP Address box.
This name must be 64 characters or fewer.
7. Enter the User Datagram Protocol (UDP) port number in the Port box. This overrides the default
UDP port number for a trap recipient with any legal, decimal UDP number.
8. Select a community string from the Community String list.
9. Click OK.
Editing trap recipients
To edit an existing trap recipient:
1. Select Monitor > SNMP Agent > Setup.
The SNMP Agent Setup dialog box is displayed (
Figure 38 on page 81).
2. Click the Trap Recipients tab.
3. Select the IP address of the trap recipient that you want to edit.
4. Click Edit.
The Edit Trap Recipient dialog box is displayed (
Figure 40 ).
Figure 40 Edit Trap Recipient dialog box
5. Edit the information as necessary.
6. Click OK.
Removing trap recipients
CAUTION: This procedure removes trap recipients without prompting you for confirmation.
To remove an existing trap recipient from the list:
