HA-Fabric Manager user guide 61
NOTE: You cannot launch SANvergence Manager or Element Manager by selecting the router
proxy port icons (domain IDs 30 and 31). You must select the icon for the actual SAN Router.
Configuring access
To configure HAFM to launch Eclipse SAN Router management applications:
1. Select SAN > Options.
The Options dialog box is displayed (
Figure 24 on page 59).
2. Select Tools Configuration in the Category list.
The Options dialog box is displayed with the Tools Configuration options (
Figure 25 ).
Figure 25 Options dialog box (Tools Configuration)
3. To configure the application to launch SAN Router Element Managers:
a. Click Browse for the HTML Browser box.
b. Browse to the install location of your web browser. For Internet Explorer, the default is
C:\Program Files\Internet Explorer
.
c. Select the browser executable file in the Locate the Browser dialog box, and then click Select
File.
For Internet Explorer, select
iexplore.exe
.
4. To configure the application to launch SANvergence Manager:
a. Click Browse for the SANvergence Manager box.
b. Browse to the install location for SANvergence Manager. The default is
C:\Program
Files\McDATA\SANvergence Manager xx
.
