Page 47

Select Configure > Group Manager.
The Group Manager dialog box is displayed (

Select Install E/OS firmware and the following tabs are displayed on the left-side:
• Select Action
• Select Switches
• Select Firmware
• Execution Options
• Install
• History

Select Action tab with Create Group Event Log selected

Select Configure > Group Manager.
The Group Manager dialog box is displayed (

Figure 11

on page 44).

Select Create Group Event Log and the following tabs are displayed on the left-side:
• Select Action
• Select Switches
• Create Log

Displaying the Select Switches tab

The Select Switches tab displays all switches and directors discovered by the HAFM appliance and

allows you to select any set of those products for use in the Group Manager.

Figure 12

Select Switches tab
