Using the HAFM application 44
When you launch Group Manager for the first time, the Select Action tab is selected with the
following options available:
• Run data collection
• Install E/OS firmware
• Create Group Event Log
Select Action tab with Run data collection selected
To access Group Manager:
1. Select Configure > Group Manager.
The Group Manager dialog box is displayed (
Figure 11 ).
2. Select Run data collection and the following tabs are displayed on the left-side:
• Select Action
• Select Switches
• Output Options
• Execution Options
• Data Collection
Figure 11 Select Group Action dialog box
Select Action tab with Install E/OS firmware selected
The Install E/OS firmware option installs firmware on a group of products.
