HA-Fabric Manager user guide 107
•
Departmental Storage Allocation—Lists the storage allocation for the entire SAN, as well as the
number of servers on the SAN for each department, number of unique LUNs assigned to those
servers, total size of those unique LUNs, and total percentage for each department. You must
have the LUN Management module to generate this report. This is an optional feature. Contact
your sales representative to purchase the module.
Generating reports
You can generate various SAN report. Generated reports are saved to
Install_Home\Server\Reports\
.
1.
Select Monitor > Reports > Generate.
The Select Template dialog box is displayed (
).
Figure 64
Select Template dialog box
NOTE:
You can generate a report of the Physical Map by clicking Generate Reports (or pressing
Ctrl-G) on the right-hand toolbox while viewing a discovered SAN.
2.
Select the type(s) of reports you want to generate.
3.
Click OK.
The generated reports are automatically displayed in the Reports dialog box.
4.
To print the report:
a. Click Show in Browser.
The selected report is displayed in your default web browser.
b. Select File > Print in the web browser.
c. Close the web browser and the Reports dialog box.
