Removing trap recipients – HP StorageWorks 2.140 Director Switch User Manual
Page 102
Configuring SAN products and fabrics
100
NOTE:
The HAFM appliance interprets trap data and displays the proper port value for all
firmware levels. When traps are generated on the switch, firmware versions 4.0 and below send the
actual port number and firmware versions 5.X and above add one to the port number to match the
specification. However, third party applications cannot correctly interpret the information.
4.
Click OK to close the Add Trap Recipient dialog box.
5.
Click OK to close the Configure Trap Forwarding dialog box.
Removing trap recipients
To remove a trap recipient:
1.
Select Monitor > Trap Forwarding.
The Configure Trap Forwarding dialog box is displayed (
2.
Highlight the recipient you want to remove from the Available Recipients list.
3.
Click Remove.
4.
Click OK.
