4–10 User’s Guide
Operating the Monitor
✎
When using the controls, you will obtain the best results by
using the adjustment pattern provided on the CD-ROM.
✎
When adjusting the Clock and Clock Phase values, if the
monitor images become distorted, continue adjusting the
values until the distortion disappears. To restore the factory
settings, select Yes from the Factory Reset menu in the OSD.
Using Video Connectors
The monitor includes the following video connectors for input
from external video sources such as DVD players, VHS
recorders, and external television tuners:
■ S-video with composite video adapter included
■ Component video
The monitor is compatible with NTSC, PAL, and SECAM
video standards. Additionally, the component video
connectors are capable of supporting the 480-line
progressive (480p), the 720-line progressive (720p), and
the 1080-line interlaced (1080i) High Definition Video
modes when connected to an external HD video decoder.
