HP ProLiant DL385p Gen8 Server - Manual (Page 16)

Component identification 16
Item Description
11 Processor 2 DIMM slots
12 Second drive cage
13 Fan connector 1
14 NMI jumper
15 Front video connector
16
Discovery services connector
17 System maintenance switch
18 SATA optical drive connector
19 SATA drive port 1
20
Power supply backplane connector
21 USB connector
22 SD card slot
23 Secondary (processor 2) PCIe riser connector
24 Processor 2 socket
25 System battery
26 TPM connector
27 Primary (processor 1) PCIe riser connector
28 Processor 1 socket
29 FlexibleLOM
30 SAS port 1i
31 SAS port 2i
32 SAS cache module connector
System maintenance switch
Position Default Function
S1 Off Off = HP iLO security is enabled.
On = HP iLO security is disabled.
S2
Off Off = System configuration can be
changed.
On = System configuration is locked.
S3 Off Reserved
S4 Off Reserved
S5 Off Off = Power-on password is enabled.
On = Power-on password is disabled.
S6 Off Off = No function
On = ROM reads system configuration
as invalid.
S7
— Reserved
S8 — Reserved
S9 — Reserved
S10 — Reserved
S11
— Reserved
S12 — Reserved
