Port Management
258 Web Tools Version 3.1.x/4.1.x User Guide
SFP Tab Example
An example of the Port Information View > SFP tab is shown in Figure 59 .
Figure 59: SFP Tab of the Port Information Window
SFP Tab Descriptions
The fields in the Port Information view > SFP tab are described in Table 64 .
Table 64: Port Information Window SFP Tab Field Descriptions
Field Description
Identifier Indicates the type of serial transceiver.
Connector Indicates the external connector type, which can be one of
the following:
■
LC (for 3800 and above).
■
GBIC (for 3600 and earlier).
ID Name Indicates the SFP model type.
