Port Management
253 Web Tools Version 3.1.x/4.1.x User Guide
About the Port Graphic
Click on the Port graphic in the Switch view to access the Port Information View.
For information regarding the Port Information view, see “
About the Port
Information View ” on page 255.
The Port graphics are numbered and have blinking LEDs. For LED status
information, refer to the switch installation guide supplied with your specific
switch (the installation guide is also available on the v3.1.x or v4.1.x Software
CD).
Port Graphic Example
The port graphic on the Switch Explorer page is interactive. You can manage a
port by clicking on the port graphic in the Switch Explorer screen. An example of
the Port graphic is shown in
Figure 57 .
Figure 57: Example port graphics (located within the Switch Graphic)
