Performance Monitoring
157 Web Tools Version 3.1.x/4.1.x User Guide
Save Canvas Configuration Example
An example of the Save Canvas Configuration option is shown in Figure 37 .
Figure 37: Save Canvas Configuration Example
Save Canvas Configuration Descriptions
The Save Canvas Configuration options are displayed in Table 37 .
Edit Select to edit the highlighted canvas configuration. A dialog
box appears, containing the following options:
■
Save - Saves a selected canvas.
■
Edit - Change specifications of a selected canvas.
■
Add - Add a graph to a canvas.
■
Remove - Remove a graph from the main canvas.
■
Cancel - Closes the Edit Canvas window.
Copy Use to make a copy of a selected canvas and save it to the
switch. The copied canvas appears in the list of canvases.
Remove Use this button to remove a selected canvas from the switch.
Close Use this button to close this dialog box.
Table 36: Display Canvas Configuration (Continued)
Field Description
