Switch Admin Window
133 Web Tools Version 3.1.x/4.1.x User Guide
Routing Field Descriptions
Descriptions of the fields available in the Routing Tab are shown in Table 29 .
These fields are displayed for all the routing tabs.
Routing (FSPF Route) Field Descriptions
Select FSFP Route Tab on the Routing Navigation tree to display the fields
described in
Table 30 .
Table 29: Routing Field Descriptions
Fields Descriptions
Dynamic Load
Sharing (DLS)
Click the appropriate radio button to turn Dynamic Load
Sharing on or off.
In-Order Delivery
(IOD)
Click the radio button to turn In-Order Delivery on or off.
Enabling IOD guarantees that frames are either delivered in
order or dropped.
Routing Navigation
Tree
Select the item in the Routing Navigation tree to be viewed,
either FSPF, Static Route, or Link Cost.
Table 30: Routing (FSPF Route) Field Descriptions
Field Description
Note: No information appears in the Routing tab if the switch has one of more ISLs
attached to itself, and no attached devices.
In Port Displays the Port number to which you want frames to come
in.
Destination Displays the destination domain ID for the participating static
routes for a particular In Port. The destination domain IDs
match the Out Ports in the cell.
Out Port Displays the Out Port. It should be within the range of ports
that are available for static routes for the current domain.
More than one Out Port can be used for any In port with a
different domain ID. Each domain ID requires an Out Port.
Metric Displays the cost of reaching the destination domain.
Hops Displays the number of hops in the “shortest path” route.
