Switch Admin Window
117 Web Tools Version 3.1.x/4.1.x User Guide
Port Settings Field Descriptions
The Port Setting fields are described in Table 23 .
Table 23: Port Setting Field Descriptions
Field Description
Port Number Displays the Port Number.
Persistent Disable Check this box to disable the port and maintain this state
over switch reboot.
Enable Port Check this box to enable a port. You can check both the
Enable Port and the Persistent Disabled boxes. This currently
enables the port, but upon a switch reboot the port is
disabled.
Enable Trunking Check this box to enable trunking on a port. Uncheck the box
to disable trunking on this port.
Enable Port Check box to enable the affiliated port. Uncheck box to
disable the port.
Port State Displays the state of the port, such as Online, No Light or No
Module.
Current Speed Displays the speed at which the port is currently set. Valid
values are:
■
1G - 1 Gbit/sec
■
2G - 2 Gbit/sec
■
N1 - Negotiated 1 Gbit/sec
■
N2 - Negotiated 2 Gbit/sec
Change Speed Use to change the port speed. Port speed can be fixed to 1G,
2G, or Negotiate (auto-negotiate). If the speed is set to
Negotiate, the subsequent current speed will display the
negotiated result.
Port Name Use optionally to assign a name to a port. The name can be
from 0 to 32 characters length. Port names do not need to be
unique. The default value is no port name.
