HA-Fabric Manager user guide 97
Figure 61 shows the dialog box you use to create a trigger phrase.
Figure 61 Trigger phrase development dialog box
Phrase operators
If the rule states that more than one operator must apply, phrase operators describe the relationship
between them. The following phrase operators are used:
• AND
• OR
• AND NOT
• OR NOT
Event triggers
Event triggers monitor system events and fire when the specified conditions exist. You can define the
phrases (rows) and their logical relationships. The phrases filter all the event context properties to
identify those events that you want to trigger the event.
Table 10 Trigger operators
Operator Value
== Number
!= Number
< Number
<= Number
> Number
>= Number
Contains String
Does Not Contain String
Starts With String
Ends With String
