HA-Fabric Manager user guide 69
7. Enter the User Datagram Protocol (UDP) port number in the Port box. This overrides the default
UDP port number for a trap recipient with any legal, decimal UDP number.
8. Select a community string from the Community String list.
9. Click OK.
Editing trap recipients
To edit an existing trap recipient:
1. Select Monitor > SNMP Agent > Setup from the HAFM menu bar.
The SNMP Agent Setup dialog box opens (
Figure 31 on page 68).
2. Click the Trap Recipients tab.
3. Select the IP address of the trap recipient that you want to edit.
4. Click Edit.
The Edit Trap Recipient dialog box opens (
Figure 33 ).
Figure 33 Edit Trap Recipient dialog box
5. Edit the information as necessary.
6. Click OK.
Removing trap recipients
To remove an existing trap recipient from the list:
CAUTION: This procedure removes trap recipients without prompting you for confirmation.
1. Select Monitor > SNMP Agent > Setup from the HAFM menu bar.
The SNMP Agent Setup dialog box opens (
Figure 31 on page 68).
2. Click the Trap Recipients tab.
3. Highlight the trap recipient that you want to remove.
4. Click Remove.
5. Click OK.
Customizing the main window
You can customize the main window by adjusting the level of detail displayed on the Physical Map
or Product List columns. This helps to simplify management of large SANs. This section provides
instructions for customizing the topology layout and creating user-defined views of the SAN.
