Band information status icons

Planned device icons

Icons of planned devices illustrate the device being unpacked from a box.

Table 29

illustrates the

planned icons for various devices.

Table 28

Band information status icons

Icon

Out-of-band

In-band

Icon

Out-of-band

In-band

Present

Not Present

Present

Present

Failed

Not Present

Present

Failed

Not Present

Present

Failed

Present

Not Present

Failed

Failed

Failed

Table 29

Planned device icons

Icon

Description

Icon

Description

Planned Host Bus Adapter

(HBA)

Planned Network

Attached Storage (NAS)

Planned switch

Planned storage

Planned hub

Planned tape

Planned bridge

Planned unknown device

Planned JBOD

Planned appliance
