English 45
hp L1520/hp L1720/hp L1820 LCD Monitor
Technical Specifications for the hp L1820 Monitor
Technical Specifications for the hp L1820 Monitor
Liquid Crystal
Display (LCD) Display Size 18 in. (46 cm) diagonal and
viewable image
Type TFT liquid crystal display
Input Signal Video 0.7 Vp-p analog RGB
Synchronization Separated H/V (TTL level)
Interface Input Connector 15-pin D-SUB (Analog)
DVI-D (Digital)
Scanning
Frequency
Horizontal 30 - 80 kHz
Vertical 56 - 75 kHz
Resolution
(H x V)
Maximum 1280 x 1024 @ 75 Hz
Recommended 1280 x 1024 @ 60 Hz
Power Source AC/DC Adapter Input Rating:
100–200 V~ auto-range,
1.5 A (1,5 A) max.
Output Rating:
12 V
, 5.8 A (5,8 A)
Frequency: 50 - 60 Hz
Base Unit Input Voltage: 12 V
Output Voltage: 4.2 A
(4,2 A)
Power Consumption Operating mode: 49 W max
Sleep mode: 2.5 W (2,5 W)
Operating
Environment
Temperature 10° C to 35° C
Humidity 20% RH through 80% RH
(without condensation)
Storage
Environment
Temperature –10° C to 60° C
Humidity 8% RH through 85% RH
(without condensation)
Dimensions
(H x W x D)
With standard stand 418 x 43 x 370 mm
(16.5 x 1.65 x 14.6 in)
Weight With standard stand: 6.5kg (6,5kg) 14.3lb
Tilt Stand Tilt Angle: Down 5, up 25 degrees
Security Lock Monitor cabinet is provided with a slot allowing the
use of Kensington lock device
