English 25
hp L1520/hp L1720/hp L1820 LCD Monitor
Adjusting the Monitor
Adjusting the Monitor
The monitor display has several adjustable settings which may need
to be fine tuned occasionally. Adjust the monitor:
• When the monitor is installed for the first time.
• If the resolution (number of pixels on the display) or refresh rate
(vertical scan frequency rate) has been changed.
• If the graphic card has been changed.
• If the monitor is connected to a different computer.
• After using the Mode Recall function. See
“To use Mode Recall” on
page 35.
NOTE: For best performance, it is recommended that you select a
video mode of 1024 x 768 @ 60 Hz for the HP L1520
monitor and1280 x 1024 @ 60 Hz for the HP L1720 and
L1820 monitors.
Using the monitor controls
There are five controls that perform the following operations:
Left browse/Brightness
Menu
Right browse/Contrast Select/Auto
On/Off
Status LED indicator
