Connecting the cables to the monitor – HP L1820 18 inch LCD Monitor User Manual
Page 16
English 15
hp L1520/hp L1720/hp L1820 LCD Monitor
Setting Up the Monitor
Connecting the cables to the monitor
Look at the following diagram and follow the steps listed below to
connect the cables to the LCD monitor.
CAUTION:
This monitor is equipped with an auto-sensing power
supply for voltage ranges 100—240 V AC, 50/60
Hz. Use the monitor with the supplied DC adapter
only.
Depending on the model that you have, the back of your monitor will
look like picture a or b.
K
K
a
b
