A S U S M 2 R 3 2 - M V P A S U S M 2 R 3 2 - M V P A S U S M 2 R 3 2 - M V P A S U S M 2 R 3 2 - M V P A S U S M 2 R 3 2 - M V P 2 - 5 2 - 5 2 - 5 2 - 5 2 - 5
I n t e r n a l c o n n e c t o r s I n t e r n a l c o n n e c t o r s I n t e r n a l c o n n e c t o r s I n t e r n a l c o n n e c t o r s I n t e r n a l c o n n e c t o r s P a g e P a g e P a g e P a g e P a g e
1. Floppy disk drive connector (34-1 pin FLOPPY) 2-26
2. IDE connectors (40-1 pin PRI_IDE) 2-26
3. Serial ATA connectors (7-pin SATA1, SATA2, SATA3, SATA4) 2-27
4. CPU, Chassis, and Power fan connectors 2-29
(4-3 pin CPU_FAN, 3-pin CHA_FAN1, 3-pin CHA_FAN2, 3-pin PWR_FAN )
5. USB connectors (10-1 USB56, USB78, USB910) 2-30
6. Power connectors (24-pin EATXPWR, 4-pin ATX12V) 2-30
7. IEEE 1394a connectors (10-1 pin IE1394_2) 2-31
8. Chassis intrusion connector (4-1 pin CHASSIS) 2-32
9. Digital audio connector (4-1 pin SPDIF_OUT) 2-32
10. Front panel audio connector (10-1 pin AAFP) 2-33
11. Audio connector (4-pin CD [black]) 2-33
12. System panel connector 2-34
- System Power LED
- Hard Disk activity
- System warning speaker
- Power/Soft-off button
- Reset switch
13. Q-Connector (System panel) 2-35
