Creating a RAID 1 configuration Creating a RAID 1 configuration Creating a RAID 1 configuration Creating a RAID 1 configuration Creating a RAID 1 configuration
To create a RAID 1 set:
1.
In the Main Menu, press <2> to enter the “Define LD” function.
2. Press , and the following screen appears.
FastBuild (tm) Utility (c) 2004-2005 ATI Technology, Inc.
[
↑↑↑↑↑]Up [↓↓↓↓↓]Down [ESC]Exit [Space] Change Option [Ctrl-Y]Save
[ Keys Available ]
[ Define LD Menu ]
[ Define LD Menu ]
Channel:ID Drive Model Capacity (MB) Assignment
1:Mas xxxxxxxxx xxxxxx Y
2:Mas xxxxxxxxx xxxxxx Y
3:Mas xxxxxxxxx xxxxxx N
4:Mas xxxxxxxxx xxxxxx N
3. Highlight the L D 1 L D 1 L D 1 L D 1 L D 1 item and press to select R A I D 1 R A I D 1 R A I D 1 R A I D 1 R A I D 1.
4. Move to the A s s i g n m e n t A s s i g n m e n t A s s i g n m e n t A s s i g n m e n t A s s i g n m e n t item by using the down arrow key and set
Y Y Y Y Y to any two of the drives .
4. Press to save the setting. The utility prompts the following
messages:
Press to key in the desired capacity or press any key to
continue.
6. The utility displays the following screen.
FastBuild (tm) Utility (c) 2004-2005 ATI Technology, Inc.
[ Define LD Menu ]
[
↑↑↑↑↑]Up [↓↓↓↓↓]Down [ESC]Exit [Enter] Select
[ Keys Available ]
LD No RAID Mode Total Drv Capacity(MB) Status
LD 1 RAID 1 2 xxxxxx Functional
LD 2 ---- ---- ---- ----
LD 3 ---- ---- ---- ----
LD 4 ---- ---- ---- ----
LD 5 ---- ---- ---- ----
LD 6 ---- ---- ---- ----
LD 7 ---- ---- ---- ----
LD 8 ---- ---- ---- ----
LD No RAID Mode Total Drv
LD 1 RAID 1 2
Strip Block: 64 KB Fast Init: OFF
Gigabyte Boundary: ON Cache Mode: WriteThru
Press Ctrl-Y to Modify Array Capacity or press any other key
to use maxinum capacity...
Press to erase MBR or press any key to continue.
Press Ctrl-Y if you are sure to erase MBR! Press any other
key to ignore this option...
