Properties window

ASM provides properties information for Exchange, Exchange storage groups, and components for
storage hosted on your HP All-in-One Storage System. The following lists the tabs available in the
properties window, and in parenthesis, if it applies to Exchange, Exchange storage groups, or
Exchange storage group components.

General tab—(Exchange, Exchange storage groups, and components) Displays the name of the
application, the total capacity reserved for the application, and its operating status:

Table 6 General tab: Exchange properties

Value

Status indicator

Exchange is running and storage is online. No alerts.

OK

See the Alerts list for more information.

Warning

See the Alerts list for more information.

Critical

Details tab — (Exchange storage groups) Displays the following Exchange server values:

Table 7 Details tab: Exchange storage group properties

Value

Property

Name of server where Exchange storage is being hosted.

Exchange Server

Version of Exchange.

Exchange Version

The number of days before log files are deleted from the server.

Days before log file removal

The domain controller used by the server.

Directory Server

The type of Exchange installation: Front-end or Back-end. ASM can only
host storage from Back-end Exchange servers, because Front-end Exchange
installations do not actually store mailboxes and other Exchange data.

Server Type

Indicates whether the server that hosts Exchange Server is part of a cluster.

Clustered

Type of Exchange replication enabled.

Replication Type

Indicates Exchange status for LCR.

LCR status

Indicates if Exchange component is the original or a copy.

LCR Copy

Path to the LCR log file copies

LCR Log Folder Copy

Path to LCR system file copies

LCR System Folder Copy

Snapshots tab — (Exchange storage groups) Allows you to schedule snapshots of the storage
group. For more information, see “

Scheduling and running snapshots

” on page 31.

Backup tab — (Exchange storage groups) Allows you to schedule backups of the storage group.
See “

Scheduling backups

” on page 34 for more information.

Replication tab — (Exchange storage groups) Allows you to configure data replication of the
storage group. See “

Running replication

” on page 37 for more information.
